Video Test |
|
|
Signal mode |
NTSC/PAL (Auto adapt) |
|
CD Screen |
5.0 inch VGA TFT-LCD, 800(RGB) x 480 resolution |
|
LCD adjustment |
Brightness, Contrast, Saturation adjustable |
|
Video IN/OUT |
1 channel BNC Input & 1 channel BNC Output |
|
VGA/HDMI input |
|
|
VGA |
Max support 1920X1080 video input |
|
HDMI |
Max support 1920X1080 video input |
|
PTZ Controller |
|
|
Communication |
Support RS485 |
|
PTZ Protocol |
Compatible with protocols PELCO-D/P |
|
Baud Rate |
600,1200, 2400, 4800, 9600, 14400bps |
|
Video Signal Generation |
|
|
Color bar generator |
Support both PAL / NTSC format’s standard color bar output (Red, Green,
Blue, White, Black, Grey) and testing image output |
|
UTP Cable Tester |
|
|
UTP cable test |
Display UTP cable connection status , cable type and the sequence of
wires as well as read the number of the test box. |
|
DC12V 1A Power Output |
|
|
DC12V power output |
Output DC12V1A power for camera |
|
Audio Input Test |
|
|
Audio input test |
1 channel audio signal input |
|
TVI Test |
|
|
TVI video signal test |
1 channel TVI input(BNC interface), support 720p 25 / 30 / 50 / 60fps,
1080p 25 / 30fps |
|
CVI Test |
|
|
CVI video signal |
test 1 channel TVI input(BNC interface), support 720p 25 / 30 / 50 / 60fps, 1080p 25 / 30fps |
|
AHD Test |
|
|
AHD video signal |
test 1 channel AHD input (BNC interface) support AHD 2.0 version, 720p 25 /30fps, 1080p 25 / 30fps |
|
Digital Multi-meter(Optional) |
|
|
AC/DC Voltage |
0-660V auto/manual range, the min resolution is 0.1mV |
|
AC/DC current |
660.0uA , 6.600mA, 66.00mA , 660.0mA, 10.00A POWER |
|
Power |
|
|
Power Adapter |
DC 5V/1.5A |
|
Battery |
Built-in 18650 2600mA battery X 2 |
|
Rechargeable |
After charging 3-4 hour, working time lasts 11 hours |
|
Low Consumption |
Energy saving , battery capacity indicator |
|
General |
|
|
Working Temperature |
-10゜~ +50゜ |
|
Working Humidity |
30% ~ 90% |
|
Dimension/ Weight |
94mm x 112mm x 48mm / 540g |
