Compatible Device |
Analog, TVI, CVI, AHD Cameras |
|
Compatible Resolution |
960H; HD720P; HD960P; HD1080P |
|
Transmission with passive receiver |
HD960P / 720P up to 250~300M around
HD1080P up to 150~250M around |
|
Coaxial Cable in/out Socket port |
Male BNC, Female BNC, F head (optional) |
|
Twisted-Pair Cable in/out socket port |
Push Terminals |
|
Coaxial Cable in/out impedance |
75Ω |
|
Twisted-Pair cable in/out impedance |
100Ω |
|
Video CMRR/ Attenuation |
60dB/ 0.3dB Typ |
|
Wire Type |
UTP CAT5,24-16AWG |
|
Working temp. / relative humidity |
-10ºC to +55ºC / <95% |
|
Weight(Net) |
50g/Pair |
