Compatible Device |
CVBS, TVI, CVI, AHD Cameras |
|
Transmission with passive receiver |
500 meter Max |
|
Coaxial Cable in/out Socket port |
BNC Connector |
|
Twisted-Pair Cable in/out socket port |
Terminals |
|
Coaxial Cable in/out impedance |
75Ω |
|
Twisted-Pair cable in/out impedance |
100Ω |
|
Video CMRR/ Attenuation |
60dB/ 0.3dB Typ |
|
Wire Type |
UTP CAT5,24-16AWG |
|
Working temp. / relative humidity |
-10ºC to +55ºC / <95% |
|
Weight(Net) |
50g/Pair |
