Model |
ST-IPR823BMS |
|
IP Camera Type |
5.0 Megapixel IP Dome Camera |
|
System |
Embedded RTOS design, dicaryon 32 bit DSP(Hi3516C), Pure hardware compression, watchdog, 32M FLASH,128M |
|
Images Sensor |
1/3" CMOS Sensor MC316DM+OV4689-2A |
|
Pixel |
1920x1080@25/30fps, |
|
Video Processing |
H.264 video Code, support Dual-stream, AVI; Support stream 0.1M-6Mpbs/ frame:1~30fps adjustable |
|
Resolution |
15fps@5MP(2592x1944); 25fps@4MP(2592x1520) |
|
Vari-focal Lens |
2.8~12mm Motorized zoom Megapixel Lens |
|
Minimum Illumination |
Color: 0.6Lux@F1.2, B/W 0.08 Lux@F1.2(IR ON ) |
|
Infrared LED |
3 PCS Array LED; 60~70 Meters IR Night Vision distance |
|
AGC/White Balance |
AUTO |
|
Day-night Switch |
Support day-night switch (ICR) |
|
Network |
Ethernet (10/100 Base-T),RJ-45 connector, support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP |
|
Function |
Support WEB configuration, OSD, real-time video transmitting, support motion detect , message, and download, video type storage, screenshot picture storage, Support CMS, remote management software |
|
ONVIF |
Support |
|
Mobile Monitor |
Support iPhone, Windows Mobile, Symbian, Android |
|
Power over Ethernet (POE) |
Optional |
|
Power Supply |
DC12V / 180mA/460mA (IR on) |
|
Working Environment |
-10 to +50 °C / 20～80%RH |
|
Dimension |
Φ87×295mm |
|
Package includes |
IP Camera x1, CD-ROM x1 (setup program and user manual) |
