Display |
4.3 inch Capacitive touch Screen , Resolution 800(RGB)x 480 |
|
Network port |
10/100M auto adapt,RJ45 |
|
WIFI |
Built in WIFI,speeds150M,display wireless camera image |
|
IP camera type |
ONVIF, ACTi, Dahua IPC-HFW2100P, Hikvision,DS-2CD864-E13, Samsung SNZ-5200, Honeywell HICC-2300T etc |
|
TVI camera type (Optional) |
Support resolution 720p 25fps,30fps,50fps,60fps; 1080P 25fps/30fps , camera OSD menu control over coaxial cable |
|
CVI camera type (Optional) |
Support resolution 720p 25fps,30fps,50fps,60fps; 1080P 25fps/30fps , camera OSD menu control over coaxial cable |
|
SDI camera test (Optional) |
1 channel SDI IN BNC Input ,Support resolution 720p 60fps / 1080p 30fps /1080i 60fps |
|
Video Signal test |
1 channel Video IN BNC input,1 channel Video OUT BNC output, support PAL/NTSC |
|
Zoom Image |
Support Analog camera and IP camera image zoom /move |
|
Snapshot, Video record and playback |
Image Screen snapshot, record ,save ,view and record and play back |
|
HDMI output |
1 channel HDMI output, Support 1920X1080P |
|
PoE power output |
48V PoE power output, Max power 24W |
|
12V/2Apower output |
Output DC12V/2A power for camera |
|
USB 5V power output |
5V 2A power output, Same as a Power bank |
|
Audio test |
1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone |
|
PTZ control |
Support RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, etc |
|
color bar generator |
Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color ) |
|
UTP Cable tester |
Test UTP cable connection status and display on the screen. Read the number on the screen |
|
Data monitor |
Captures and analyzes the command data from controlling device, also can send hexadecimal |
|
Network test |
IP address scan, link test, Ping test, Quickly search the connection IP camera and other device’s IP address |
|
External power supply |
DC 12V（2A） |
|
Battery |
Built-in 7.4V Lithium polymer battery , 5000mAh |
|
Rechargeable |
After charging 7~8 hours, normal working time 16 hours |
|
Operation setting |
Capacitive touch screen, OSD menu, Chinese/English |
|
Auto off |
5-30 (mins) |
|
Working Temperature |
-10℃---+50℃ |
|
Working Humidity |
30%-90% |
|
Dimension/Weight |
212mm×135.5mm×56.5mm / 0.75Kg |
