Video test |
Video System |
NTSC/PAL Automatically recognize |
|
Video level |
1VPP |
|
|
Display screen |
4.3-inch LCD 480 * RGB * 272 (QVGA) resolution, 64K color |
|
|
Screen adjustment |
Video display brightness, contrast, color saturation adjustable, LCD backlight brightness adjustable |
|
|
Video input / output |
1 channel BNC Video IN |
|
|
Hd & simulation test |
SD signal Format |
NTSC ,PAL |
|
HD video signal |
HD AHD,TVI,CVI |
|
|
Resolution |
D1,720P,960p,1080P |
|
|
Signal Level |
1Vpp |
|
|
12V power output |
Power output |
Output 12V 1A dc power supply, provide temporary working power for camera |
|
The USBX1 5V1A output is powered by the camera |
||
|
Audio test |
Audio test |
Input audio signal, and played on the internal speaker |
|
Power supply |
External power |
DC 5V(2A) |
|
Battery-powered |
Built-in 3.7V polymer lithium battery, capacity 2600mAh |
|
|
Charge |
Charge 3-4 hours, and can be used for 8 hours at a time |
|
|
Power saving features |
Low power consumption, automatic standby power saving power, battery power icon display in real time |
|
|
System settings |
Language settings |
Chinese, English user selectable |
|
Auto power off |
Disable / 5-60 minutes |
|
|
Cable test |
cable test |
Test any two or more wires, and the connection sequence and test header Numbers are displayed on the screen |
|
LED Light |
35lm LED light, an emergency lighting |
|
|
Working environment and specification |
Working humidity |
30%-90% Rh |
|
Operating temperature |
-20℃---+70℃ |
