LCD screen |
5.0 inch TFT-LCD, 800(RGB)x 480 resolution |
|
|
Video test |
NTSC/PAL (Auto adapt) |
|
|
LCD adjustment |
Brightness, Contrast, Saturation adjustable |
|
|
Video IN/OUT |
1 channel BNC Input & 1 channel BNC Output |
|
|
VGA/HDMI input |
NOT Support
|
|
|
PTZ Controller |
Support RS485 |
|
|
PTZ Protocol |
Compatible with protocols PELCO-D/P, |
|
|
Baud Rate |
Baud Rate: 600,1200, 2400, 4800, 9600, 14400bps |
|
|
Color bar generator |
Support both PAL / NTSC format’s standard color bar output |
|
|
(Red, Green, Blue, White, Black, Grey) and testing image output |
||
|
UTP Cable Test |
Display UTP cable connection status , cable type and |
|
|
the sequence of wires as well as read the number of the test box. |
||
|
DC12V power output |
Output DC12V1A power for camera |
|
|
Audio input test |
1 channel audio signal input |
|
|
Coaxial HD test |
||
|
TVI test |
1 channel TVI input(BNC interface), |
|
|
support 1MP 2MP 3MP 4MP 5MP |
||
|
CVI Test |
1 channel TVI input(BNC interface), |
|
|
support 1MP 2MP 3MP 4MP |
||
|
AHD Test |
1 channel AHD input (BNC interface), |
|
|
support AHD 2.0 version, 1MP 2MP 3MP 4MP 5MP |
||
|
POWER |
||
|
Power Adapter |
DC 5V(1.5A) |
|
|
Battery |
Built-in 18650 2600mA battery X 2, |
|
|
After charging 3-4 hour, working time lasts 11 hours |
||
|
General |
||
|
Language |
English and Chinese optional |
|
|
Working Humidity |
30%-90% |
|
|
Dimension |
194mm x 112mm x 48mm / 540g |
|
