DVR specification
|
Video in/output |
|
|
Video compression |
H.264 |
|
Analog video input |
8x BNC (Level: 1.0Vp-p, impedance : 75Ω) |
|
Multi-mode switch |
1.8x1080P Analog
2.4x1080P IPC
3. 9x3MP IPC
4.4x5MP IPC |
|
HDMI/VGA output |
1920x1080, 1024x768,1280x720,1280x1024 |
|
CVBS output |
1x BNC (Level: 1.0Vp-p, impedance : 75Ω) |
|
Encoding resolution |
AHD/TVI/CVI: 8CH*1080P@100/120fps; IPC 4CH*5MP@40fps; 9CH*3MP@145fps |
|
Playback resolution |
1CH 1080P@15fps or 8CH CIF real time playback |
|
Frame rate |
NTSC:1~30FPS; PAL:1~25FPS |
|
Video bit rate |
256KB/384KB/512KB/640KB/768KB/1MB/1.5MB/2MB/2.5MB/3MB/4MB/5MB/6MB/8MB |
|
Audio in/output |
|
|
Audio compression |
ADPCM |
|
Audio input |
4x RCA (Level : 2.0Vp-p, impedance : 1kΩ) |
|
Audio output |
1xRCA ( line level , impedance : 1kΩ) |
|
Audio bit rate |
16kpbs |
|
Dual-stream |
Support |
|
Stream type |
combine streams/ video stream |
|
Hard disk |
|
|
SATA |
1xSATA |
|
eSATA |
No |
|
Capacity |
Up to 4TB |
|
External interface |
|
|
Network interface |
1xRJ45 10M / 100M adaptive Ethernet port |
|
Serial interface |
1xRS485 |
|
USB interface |
2xUSB2.0 |
|
Alarm in/out |
NO |
|
General |
|
|
Power supply |
DC12V |
|
Consumption |
≤20W |
|
Working Temp. |
-10oC-+50oC |
|
Working humidity |
10%-90% |
|
Dimension |
255*215*45mm (L*W**H) |
|
Net Weight |
1.00kg |
Camera specification
|
Image sensor |
1/2.7" CMOS sensor |
|
Chipset |
NVP2441H+AR0237 |
|
Effective Pixels |
1920(H)×1080(V) |
|
IR LED , Lens |
24PCS IR LED . 3.6mm lens |
|
IR Distance |
20m |
|
Lowest illumination |
0.02Lux@(F1.2, AGC ON), 0 Lux (IR ON) |
|
OSD Menu |
Ssupport, coaxial cable control via DVR directly (UTC) |
|
Electronic Shutter |
1/50s~1/60,000s |
|
Video Frame Rate |
25/30fps@2048×1536P |
|
Video Output |
1 channel |
|
Smart IR Control |
Support |
|
Day/Night |
Auto(ICR) / Color / B/W |
|
Digital WDR |
Support |
|
SNR |
>50 dB |
|
Noise Reduction |
2D/3D DNR |
|
Working Environment |
-20°C~+50°C / Less than 95%RH |
|
Power Consumption |
< 5W |
|
Power Supply |
DC12V±10% |
|
Weight |
0.5KG |
