FEATURES
This HDMI Extender has many features that enable it to perform in superior manner, among those features and you will find:
1) One pair as a full functional module, no need of setting.
2) CAT-5e/6 cable can substitute HDMI cable to achieve long distance transmission.
3) CAT-5e/6 follow the standard of IEEE-568B
4) Transmission distance can be up to 60 meters for 1080p while using CAT-5e/6 cable.
5) Compact size
6) Signaling rates up to 1.65Gbps in support of 1080p display.
7) HDCP compliant
8) Support uncompressed audio such as LPCM
9) Support compressed audio such as DTS Digital, Dolby Digital (including DTS-HD and Dolby true HD)
|
Input video signal |
0.5-1.0 volts p-p |
|
Input DDC signal |
5volts p-p(ttl) |
|
Maximum single link range |
1920*1080, 1080p |
|
Output video |
HDMI |
|
DTV/HDTV |
1080p/1080i/720p/576p/480p/576i/480i |
|
Distance |
60meters |
|
Interlaced(50&60hz) |
480i 576i 1080i |
|
Progressive(50&60hz) |
480p 576p 720p 1080p |
|
Power consumption |
5wattd(max) |
|
Operating temperature |
0 to+70℃ |
|
Operating humidity |
10%to85%RH(no condensation) |
|
Storage temperature |
-10℃to+80℃ |
|
Storage humidity |
5%to95%RH(no condensation) |
|
External power supply |
DC5V @1A |
