Sensor |
1/3" CMOS 2MP SONY323 |
|
Output pixel |
1920x1080/30fps,1920x1080/25fps |
|
Lens |
10X f=5.1~51mm |
|
BLC |
Support |
|
AGC |
Auto/Maniual |
|
WB |
Indoor/Outdoor/Auto/Manual |
|
S/N Ratio |
≥50dB |
|
WDR |
DWDR |
|
Rotation Range |
Pan: 0°~360° , Tilt: 0°~93° |
|
Rotation Speed |
Pan: 0~80°/s , Tilt:0~40°/s |
|
Auto Flip |
Horizontal 180°, Vertical 93° |
|
Preset Points |
220pcs preset( Dwell time 01-60s interval available) |
|
A-B Scan |
User programmable (scan speed 1-64 levels setting available ) |
|
Guard Tours |
3 groups (Max.16 points, dwell time user select-able) |
|
PWR On Action |
Memory/Pattern 1/Tour 1/360° scan/A-B scan/Park 1/None |
|
Video interface output |
AHD/TVI/CVI/CVBS select-able |
|
Communication mode |
RS485 (+/-) / coaxial cable |
|
Operating Temperature |
-40℃~+60℃ |
|
Power |
DC12V 4A |
|
Power Consumption |
≤ 25W |
|
Lightning Protection |
Transient voltage 6000V |
|
Auto Control IR LED |
PWM |
|
IR distance |
Up to 60 meters |
|
LEDs |
6PCS Array 42Mil IR LED |
|
Support ambient light detection |
IR illumination on 1-9 grades select-able |
