Sensor |
1/3" CMOS 2MP SONY323 |
1/3" CMOS 2MP SONY323 |
|
Output pixels |
1920x1080/30fps |
1920x1080/30fps |
|
Lens |
20X 4.7mm~94mm |
36X 4.6mm~165mm |
|
BLC |
Support |
|
|
AGC |
Auto/Manual |
|
|
WB |
Indoor/Outdoor/Auto/Manual |
|
|
S/N Ratio |
≥50dB |
|
|
D-WDR |
Support |
|
|
Rotation Range |
Pan: 0°~360°, Tilt: 0°~93° |
|
|
Rotation Speed |
Pan: 0~400°/s, Tilt:0~200°/s |
|
|
Auto Flip |
Horizontal 180°, Vertical 93° |
|
|
Preset Points |
220pcs preset( Dwell time 01-60s interval available) |
|
|
Guard Tours |
8 groups (Max.16 points, dwell time user selectable) |
|
|
PWR On Action |
Memory/Pattern 1/Tour 1/360° scan/A-B scan/Park 1/None |
|
|
Park Mode |
Pattern 1/Tour 1/360° scan/A-B scan/Park 1/None |
|
|
Park Time |
1-60mins available |
|
|
Pattern Scan |
4 pcs(Max.15 minutes, max.512 commands) |
|
|
Time Scheduling Function |
6 tasks |
|
|
Video interface output |
AHD/TVI/CVI/CVBS select-able |
|
|
Communication mode |
RS485 (+/-) / coaxial cable |
|
|
Alarm function |
Support, 4in,2out |
|
|
Operation menu |
Multiple languages for OSD menu, English, Italian,Spanish etc.; |
|
|
Operating Temperature |
-40℃~+60℃ |
|
|
Power |
DC12V 4A / (AC24V 3A optional ) |
|
|
Power Consumption |
≤ 25W |
|
|
Lightning Protection |
Transient voltage 6000V |
|
|
Auto Control IR LED |
PWM |
|
|
IR distance |
Up to 150 meters |
|
|
IR LED |
10PCS Array 42Mil IR LED |
|
|
Support ambient light detection |
IR illumination on 1-9 grades select-able |
|
