Model |
ST-IP204C |
|
IP Camera Type |
2.0 Megapixel IP Dome Camera |
|
System |
Embedded RTOS design,dicaryon 32 bit DSP(HI3516C),Pure Hardware compression, watchdog ,16M FLASH,128M DDR3 |
|
Images Sensor |
1/3 inch 2.0 Megapixel Sensor |
|
Pixel |
1920x1080@25/30fps |
|
Video Processing |
H.264 video Code, support Dual-stream, AVI; Support stream 0.1M-6Mpbs adjustable |
|
Video output |
Main Stream 1280×720; Sub stream: 640×360,320×180 |
|
Resolution |
2MP:1920x1080@25fps, 720P:1280x720@25fps - Adjustable |
|
Video bit rate |
2.0 megapixel 25/30 frames(real time),Support 1-25/30 frames/second adjustable |
|
Vari-focal Lens |
3.7mm Pinhole Megapixel Lens |
|
Minimum Illumination |
Color: 0.1Lux@F1.2, B/W 0.01 Lux@F1.2(IR ON ) |
|
Infrared LED |
12 PCS;15 Meters IR Night Vision distance |
|
AGC/White Balance |
AUTO |
|
Day-night Switch |
Support day-night switch (ICR) |
|
System Sync |
Inter Sync |
|
Network |
Ethernet (10/100 Base-T),RJ-45 connector, support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP |
|
Function |
Support WEB configuration, OSD, real-time video transmitting, support motion detect , message, download, video type storage, screenshot picture storage, Support CMS, remote management software |
|
ONVIF |
Support |
|
Mobile Monitor |
Support iPhone, Windows Mobile, Black Berry, Symbian, Android |
|
Power over Ethernet (POE) |
Optional |
|
Power Supply |
DC12V / 180mA/460mA (IR on) |
|
Working Environment |
-10 to +50 °C / 20～80%RH |
|
Package includes |
IP Camera x1, CD-ROM x1 (setup program and user manual) |
