Model |
ST-IPD607V |
|
IP Camera Type |
5.0 Megapixel IP Camera |
|
System |
Embedded RTOS design, dicaryon 32 bit DSP, Pure hardware compression, watchdog, 32M FLASH,128M |
|
Images Sensor |
1/2.5-inch 5 Megapixel Ambarella DSP 3516D+OV4689-2A |
|
Pixel |
5MP: 2592x1944@15fps |
|
Video Processing |
H.264 video Code,support Dual-stream, AVI; Support stream 0.1M-6Mpbs/ frame: 1~30fps djustable |
|
Video output |
Main Stream 1920×1080; Sub stream: 704×576 |
|
Resolution |
Full HD1080P; 5MP: 2592x1944@15fps, 4MP:2592×1520@25fps, 3MP:2048x1520@25fps, 2MP:1920x1080@30fps - Adjustable |
|
Board Lens |
3.6mm Megapixel Lens(3 Megapixels) |
|
Minimum Illumination |
Color: 0.6Lux@F1.2, B/W 0.08 Lux@F1.2(IR ON ) |
|
Infrared LED |
12PCS IR LED; 20 Meters IR Night Vision distance |
|
AGC/White Balance |
AUTO |
|
Day-night Switch |
Support day-night switch (ICR) |
|
Network |
Ethernet (10/100 Base-T),RJ-45 connector, support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP |
|
Function |
Support WEB configuration, OSD, real-time video transmitting, support motion detect, message, download, video type storage, screenshot picture storage, Support CMS, remote management software |
|
ONVIF |
Support |
|
Mobile Monitor |
Support iPhone, Windows Mobile, Black Berry, Symbian, Android |
|
Power over Ethernet (POE) |
Optional |
|
Power Supply |
DC12V / 180mA/350mA (IR on) |
|
Working Environment |
-10 to +50 °C / 20～80%RH |
|
Package includes |
IP Camera x1, CD-ROM x1 (setup program and user manual) |
